DECK ASSEMBLY
STEP 5
NOTE HOLE LOCATION IS
CLOSER TO THE TOP EDGE.
LAG SCREW WH BLK
5/16x2
(x4)
H100458
FLOOR RAIL - W4L14888
1"x3 3/8"x56 3/4" (24x86x1442)
H1
(x1)
WASHER LOCK EXT BLK
8x19
(x4)
H100198
198 (x4)
WASHER - 8x19
458 (x4)
LAG SCREW - 2"
H1 (x1)
