DECK ASSEMBLY
STEP 4
LAG SCREW WH BLK
5/16x2
(x4)
H100458
WASHER LOCK EXT BLK
8x19
(x4)
H100198
198
(x4)
WASHER - 8x19
458
(x4)
LAG SCREW - 2"
SUBASSEMBLY
FROM STEP 3.
34
