Backyard Discovery Echo Heights - Page 37

DECK ASSEMBLY
STEP 7
NOTE T-NUT OUTWARD
THIS LOCATION ONLY.
378 (x8)
BOLT - 1 3/4"
198 (x8)
WASHER - 8x19
403 (x8)
LAG SCREW - 1 1/2"
405 (x8)
WASHER - 6x15
379 (x8)
T-NUT - 5/16"
H20 (x8)
DECK BRACE - W4L14898
1"x3 3/8"x13" (24x86x330)
H20
(x8)
BOLT WH BLK
5/16x1 3/4
(x8)
H100378
WASHER LOCK EXT BLK
8x19
(x8)
H100198
WASHER LOCK EXT BLK
6x15
(x8)
H100405
LAG SCREW WH BLK
1/4x1 1/2
(x8)
H100403
T-NUT BLK
5/16
(x8)
H100379
37
