DECK ASSEMBLY
STEP 8
FLOOR SUPPORT - W4L14892
1"x3 3/8"x54 7/8" (24x86x1394)
H5
(x2)
SCREW PFH BLK
8x2-1/2
(x8)
H100201
FLUSH TOPS
ALL LOCATIONS
H5
(x2)
201
(x8)
SCREW - 2 1/2"
38
