DECK ASSEMBLY
STEP 13
WALL RAIL - W4L14897
1"x3 3/8"x16 3/4" (24x86x426)
H10
(x2)
RAIL BOARD - W4L14920
1"x1"x26 3/4" (24x24x679)
S1
(x1)
200 (x4)
SCREW - 1 1/2"
458 (x2)
LAG SCREW - 2"
198 (x2)
WASHER - 8x19
SCREW PFH BLK
8x1 1/2
(x4)
H100200
NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
WASHER LOCK EXT BLK
8x19
(x2)
H100198
LAG SCREW WH BLK
5/16x2
(x2)
H100458
H10 (x1)
H10 (x1) S1 (x1)
