Backyard Discovery Echo Heights - Page 75

FINAL ASSEMBLY
STEP 2
PLAYHOUSE SUBASSEMBLY
(x1)
408 (x8)
SCREW - 1/2"
555
90° L-BRACKET - BLK
(ASSEMBLED PREVIOUSLY)
SCREW PWH BLK
8x1/2
(x8)
H100408
382 (x4)
SCREW - 1 3/4"
PICKET MAY NEED TO BE
TEMPORARILY REMOVED
TO ASSEMBLE THE HOUSE
TO THE DECK.
PICKET MAY NEED TO BE
TEMPORARILY REMOVED
TO ASSEMBLE THE HOUSE
TO THE DECK.
382 (x4)
SCREW - 1 3/4"
SCREW PFH BLK
8x1 3/4
(x8)
H100382
75
