FINAL ASSEMBLY
STEP 3
12 1/4 in
[
312 mm]
202
(x2)
SCREW - 5/8"
528
(x1)
BYD ID TAG (MEDIUM) AGES 2 TO 10
BYD ID TAG (MEDIUM) AGES 2 TO 10
(x1)
A4M00528
SCREW PWH BLK
8x5/8
(x2)
H100202
76
