FINAL ASSEMBLY
STEP 4
GROWTH BOARD - W4L14908
5/8"x3 3/8"x60 1/4" (16x86x1530)
M1
(x1)
SCREW PFH BLK
8x1 1/8
(x4)
H100380
3 1/8 in
[
80 mm]
M1
(x1)
380
(x4)
SCREW - 1 1/8"
77
