STEP 7
NOTE:
FINAL ASSEMBLY
VERTICAL ID PLATE
(x1)
A4M01150
SCREW PPH WZ
4x1/2
(x4)
H100360
360
(x4)
SCREW - 4x1/2" WZ
150
(x1)
VERTICAL ID PLATE
1/2 in
[12mm]
CENTER ID PLATE ON UPRIGHT
