Backyard Discovery OAKMONT - Page 24

SLIDE ASSEMBLY
STEP 2
M78 - CENTER SLIDE BRACE - W4L04712
5/8"x3 3/8"x14 1/4" (16x86x362)
(2)
SCREW PFH
8x2 1/2
(24)
TIP: A HELPER IS REQUIRED FOR THIS STEP.
NOTE:
MAKE CERTAIN SUPPORTS
AND SLIDE BED ARE FULLY
ENGAGED WITHIN CHANNEL
OF SLIDE RAILS.
M78
SLIDE RAIL 8' GREEN LEFT
(1 PLC)
SLIDE RAIL 8' GREEN RIGHT
(1 PLC)
SCREW PFH 8x2 1/2
(24 PLCS)
EK - SLIDE RAIL 8' GREEN RIGHT - A100054
(1)
EL - SLIDE RAIL 8' GREEN LEFT - A100055
(1)
