Backyard Discovery OAKMONT - Slide Assembly; BOLT WH 5;16 X1

SLIDE ASSEMBLY
STEP 1
M77
SLIDE BED 8' YELLOW
(1 PLC)
TIP: PREBENDING THE ENDS WILL EASE ASSEMBLY.
BOLT WH
5/16x1/2
(2)
-
S
L
I
D
E
B
E
D
8
'
Y
E
L
L
O
W
-
A
6
P
0
0
0
3
3
(
1
)
M77 - SLIDE BRACE - W4L04711
5/8"x3 3/8"x14 1/4" (16x86x362)
(1)
USE 'M77' SLIDE BRACE AS A
TEMPLATE FOR DRILLING BOTTOM
HOLE PATTERN IN SLIDE BED. BE SURE
TO PLACE SLIDE BRACE UP 1/4" FROM
BOTTOM EDGE OF SLIDE BED BEFORE
MARKING HOLE PATTERN.
1/4"
T-NUT 5/16
(2)
T-NUT 5/16
(2 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
