Backyard Discovery OAKMONT - Nut Lock; Washer; FLAT 8 X27

SWING BEAM ASSEMBLY
STEP 4
NUT LOCK 5/16
(6 PLCS)
WASHER FLAT 8x27
(6 PLCS)
WASHER SAFETY 17x30
(6 PLCS)
SWING HANGER QUICK LINK
(6 PLCS)
WASHER
FLAT 8x27
(6)
NUT LOCK
5/16
(6)
BZ - SWING HANGER QUICK LINK - H100099
(6)
WASHER
SAFETY
17x30
(6)
1. Lock nut must be tightened
until loop is tight against
the safety washer.
2. Swing hanger bolt must be
oriented as shown to avoid
damage to swing hanger bolt.
