Backyard Play Systems 5027 - Page 30

26
ROCK WALL ASSEMBLE
All flush
2-1/2" Wood Screws
x24
23-3/4"
23-3/4"
Ensure all plank ends are ush, making sure screws install into rails.
ROCK WALL ASSEMBLE
1/4" x 1-1/4" Hex Bolts
1/4" Lock Washers
T-Nuts
1/4" Flat Washers
Pre-drill 5/16" pilot holes.
Do NOT attach top
board at this time.
x1 BAG
WS 4542
