Backyard Play Systems 5027 - Page 39

35
A - FRAME ASSEMBLE
T-Nut x2
x2
3 x 3 x 95"
2525-CC
Rotate 2525-CC 180
o
after
installing T-Nuts.
A - FRAME ASSEMBLE
x1
x2
3-3/4" Hex Bolt
Lock Washer
Flat Washer
1 x 3-1/2 x 68-1/2"
2506-CC
Pre-installed T-Nuts
are underneath.
