36
FLAT PLATESWING BEAM
3" Carriage Bolt
x2
Flat Washer
Lock Nut
x2
2411
x1
A - FRAME 90
o
PLATE
3-3/4" Carriage Bolt
Lock Nut
Flat Washer
x2
2525-CC
2499
x1
Flat Washer
Lock Nut
