SWING BEAM ANGLED PLATES
4-1/4" Carriage Bolt
Flat Washer
Lock Nut
x2
x2
x1
3-3/8 x 5-3/8 x 95”
2502-CC
2448
2447
x1
x1
DO NOT FULLY TIGHTEN
CARRIAGE BOLTS AT THIS TIME
NOTE: You may need to tap bolts with
hammer to get though holes.
Clean all debris from bolt threads
before installing lock nuts
SWING BEAM ASSEMBLE
Position swing beam assembly resting upon A-frame.
