LADDER ASSEMBLY
STEP 3
LADDER ASSEMBLY
STEP 4
M103 - REAR SUPPORT - W4L06932
5/8"x3 3/8"x18 1/4" (16x86x462)
(1)
M102 - ATTACHMENT BOARD - W4L06934
5/8"x3 3/8"x18 1/4" (16x86x462)
(1)
SCREW PFH
8x1 1/2
(4)
SCREW PFH
8x1 1/2
(4)
SCREW PFH 8x1 1/2
(4 PLCS)
SCREW PFH 8x1 1/2
(4 PLCS)
M103
M102
FLUSH TO TOP.
