STEP 14
SCREW PFH 8x1 3/4
(8 PLCS)
J2
J2
J2
J2
H2
H3
J2 - FLOOR SUPPORT - W4L06710
1
"x2 3/8"x3" (24x60x76)
(4)
SCREW PFH
8
x1 3/4
(8)
5/8" DOWN
TYP
41
