STEP 15
SCREW PFH
8x1 3/4
(10)
SCREW PFH 8x1 3/4
(10 PLCS)
T1
T1
5/8" TYP
BOTH SIDES
T1
T1 - SUPPORT BOARD - W4L07140
1"x1 3/8"x44 1/8" (24x34x1122)
(2)
