STEP 18
ASSEMBLE T-NUTS INTO BOARDS BEFORE INSTALLATION.
BOLT WH
5
/16x1 3/4
(1)
T-NUT 5/16
(2)
WASHER
LOCK EXT
8x19
(2)
BOLT WH 5/16x1 3/4
(1 PLC)
WASHER LOCK EXT 8x19
(1 PLC)
T-NUT 5/16
(1 PLC)
H7
H7 - UPRIGHT - W4L07148
1
"x3 3/8"x72" (24x86x1828)
(1)
T-NUT 5/16
(1 PLC)
BOLT WH 5/16x1 1/2
(1 PLC)
WASHER LOCK EXT 8x19
(1 PLC)
BOLT WH
5
/16x1 1/2
(1)
45
