Backyard 720-0789D User Manual

54
No.
Part (Description)
Warranty
Coverage (Year)
QTY No.
Part (Description)
Warranty
Coverage (Year)
QTY
1 Main lid
2
1 25 Side burner cooking grid
2
1
2 Main lid screw
2
2 26 Side burner lid
2
1
3 Temperature gauge
2
1 27 Side burner lid hinge rod
2
1
4 Logo
2
1 28 Side burner
2
1
5 Hood buffer A
2
2 29 Side burner igniter wire
2
1
6 Main lid handle assembly
2
1 30 Grease tray
2
1
7 Warming rack
2
1 31 Grease box bracket
2
1
8 Cooking grid
2
2 32 Grease box
2
1
9 Flame tamer
2
4 33 Cart leg front, left
2
1
10 Hood buffer B
2
2 34 Cart leg rear, left
2
1
11 Main burner bowl assembly Non-replaceable 1 35 Cart frame top, right & left
2
2
12 Side shelf, left
2
1 36 Cart frame bottom, left
2
1
13 Burner pin assembly
2
5 37 Cart foot
2
2
14 Main burner
2
4 38 Rear cart frame
2
1
15 Main burner igniter wire
5
4 39 Front panel
2
2
16 Main manifold
2
1 40 Cart leg front, right
2
1
17 Main gas valve
2
4 41 Cart leg rear, right
2
1
18 Side burner flex gas line
2
1 42 Second tank wire A
2
1
19 Side burner gas valve
2
1 43 Second tank wire B
2
1
20 LP regulator with hose
2
1 44 Tank wire
2
1
21 Main control panel
2
1 45 Lighting rod
2
1
22 Bezel
2
4 46 Cart frame bottom, right
2
1
23 Control knob
2
5 47 Wheel
2
2
24 Side burner shelf, right
2
1 48 Wheel hardware 2 2
