Backyard PRO - Step 9: Knob Base and Knob Assembly; Step 10: Side Burner Attachment

10
Assembly Instrucons
Step 9
Mount knob base (26) to front of
side burner body using BOLT M4*8
(HH) - 2 PCS.
Push knob (36) into side burner
controller.
Step 10
Assemble the side burner (29) by
sliding it on the top center of the
side burner body.
Secure burner to body using BOLT
M4*8 (HH) - 2 PCS.
Ax the terminal to gas controller as
shown in Fig. 3.
