SPECIFICATIONS
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
Page 2 - 2
2
VEHICLE SPECIFICATIONS
2013 Bad Boy Buggies - Ambush
Released: June 2012
Specifications are subject to change without notice
* Field installed accessories may require installation charges
MODEL: BAD BOY BUGGIES - AMBUSH
TYPE: GAS / ELECTRIC PARALLEL DRIVE VEHICLE
MODEL YEAR: 2013
Part No:. 626640
Engine: 16 hp (11.9 kW) rated, 4 cycle, 29.2 ci (480 cc) V-Twin, air-cooled Vanguard
z Valve Train: Overhead valve z Fuel System: Fixed float bowl with remote pulse fuel pump
z
Lubrication: Pressurized oil system, spin-on oil filter z Ignition: Electronic spark/magneto
z Balancer: Internal counter rotating balance shaft z Air Cleaner: Replaceable dry cartridge w/permanent pre-filter
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (525 CCA, 60 minute reserve)
Drive Train Gas
Automatic, continuously variable transmission (CVT). Locking rear axle (Operator selectable from center console)
Drive Train Ele
48 V DC (8 Brush) With Speed Sensor
Brakes: 4 wheel hydraulic brakes (Disc Front, Drum Rear). Hand operated park brake located in center console
Transaxle: Differential with helical gears, ground speed governor, forward/reverse
Seating: Two bucket seats
Cargo Bed:
Roto-molded cross-linked polyethelene. Lifts for access to powertrain. Removable hinged multi-position tailgate requires no latch mechanism
Dimensions Vehicle Power Cont.
Overall Length 115.5 in (293.4 cm) Gear Selection Forward-Reverse
Overall Width 54.5 in (138.4 cm) Front Axle Ratio
12.44:1
Overall Height 53 in (134.6 cm) Top of steering wheel Rear Axle Ratio 13.32:1 Fwd; 14.01 Rev
75.5 in (192 cm) with OPS Performance
Wheel Base 79.5 in (202 cm) Seating Capacity 2 Persons
Front Wheel Track 43.75 in (111 cm) Curb Weight 1700 lb (772 kg)
Rear Wheel Track 43.25 in (110 cm) Bed Load Capacity 500 lb (225 kg)
Gnd Clearance @ Differential
7.5 in (19 cm) Vehicle load capacity 800 lb (360 kg)
Cargo Box Width (inside) 44.0 in (112 cm) Outside Clearance Circle
29 ft (8.8 m)
Cargo Box Length (inside) 36.0 in (91 cm) Speed (Level Ground) 2WD Elec: 16 mph ± 0.5 mph (25.7 kph ± 0.8 kph)
Cargo Box Depth (inside)
10.5 in (27 cm) 4WD : 25 mph ± 1 mph (40.1 kph ± 1.6 kph)
Cargo Box Capacity 9.6 cu ft (0.27 m3)
Towing Capacity
500 lb (225 kg)
Cargo Box Material Roto-molded polyethylene Steering & Suspension
Vehicle Power Steering Self-compensating rack and pinion
Power Source GAS: 4 cycle, 29.2 ci (480 cc) Front Suspension Independent Mc Pherson Strut
Elec: 48V DC motor Rear Suspension Leaf springs with hydraulic shock absorbers
Valve Train V Twin Cylinder OHV Service Brake 4 wheel hydraulic (disc front,drum rear)
Horsepower (kW) GAS 16 hp (11.9 kW) rated Parking Brake Hand Operated
Elec 20.6 hp (15.4 kW) pk Front Tires MudLite 25x10-12 Uni-Directional
Electrical System Starter/Generator, solid-state regulator Rear Tires MudLite 25x10-12 Uni-Directional
Battery (Qty, Type) One 12 Volt maintenance free for starter / gen Body & Chassis
4x12 V for Elec Drive Frame Welded steel with DuraShield™ powder coat
Key or Pedal Start Pedal Start Front Body & Finish Injection Molded TPO
Air Cleaner Dry cartridge w/permanent pre-filter Rear Body & Finish Steel. Base coat/clear coat
Lubrication Pressurized oil system Standard Color Matte Black
Oil Filter Spin-on oil filter
Cooling System Air cooled
Fuel Capacity 5.3 gallon (20 L) tank
Differential Helical gears with manual lock-up (Rear Only)
