Page 4 - 5
OPERATION
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
4
Hydrogen gas is generated in the charging cycle of batteries and is explosive in concentrations as low as 4%.
Because hydrogen gas is lighter than air, it will collect in the ceiling of buildings necessitating proper ventilation.
Five air exchanges per hour is considered the minimum requirement.
Never charge a vehicle in an area that is subject to flame or spark. Pay particular attention to natural gas or propane
water heaters and furnaces.
PORTABLE CHARGER
The portable charger will charge ONLY the battery set for the electric motor, not the single battery used for starting
the gas engine.
Installation
Use charger ONLY on 48 volt battery systems. Other usage may cause personal injury and dam-
age. Lead acid batteries may generate explosive hydrogen gas during normal operation. Keep
sparks, flames, and smoking materials away from batteries. Provide adequate ventilation during
charging. Never charge a frozen battery. Study all battery manufacturers’ specific precautions
such as recommended rates of charge and removing or not removing cell caps while charging.
Provide Protection From Elements
Keep cooling fins clean and free of dirt and debris
NEMA 15 - 5R Grounded AC Receptacle
110 - 120 VAC. Dedicated 15 AMP Circuit
Locations outside the US and Canada: Reference
appropriate local electrical code and charger manu-
facturer recommendations for AC power requirements
Mounting Holes
Hanging Holes
3.1"
(7.89 cm)
