PAGE 14
SECTION 8: MOVING INOPERABLE MOWER
8.1 Do not tow machine. Use a winch to load on a trailer for transporting.
8.2 If it becomes necessary to move an inoperable mower, the drive pumps are equipped with bypass
valves that allow the drive tires to rotate freely. These bypass valves are located on top of the pumps.
Each require a quarter turn to allow for proper bypass.
***Weights fluctuate with the addition of accessories.
8.3 As you can see by the weights of the machines, you shouldn’t ever try to push or pull a Bad Boy Mower
by hand. This could cause serious bodily injury.
8.4 Hopefully, you’ll never need to use this section of the manual. However, if you do, use extreme caution
when moving machine!
SECTION 9: INSTRUMENTATION
9.1 Coolant Temperature Gauge: The Renegade diesel is equipped with a coolant temperate gauge for
monitoring engine temperature.
9.2 Oil Pressure Gauge: The Renegade diesel is equipped with a oil pressure gauge for monitoring
engine oil pressure.
9.3 Electronic Hour Meter: Registers Hour increments up to 9,999.9 total hours. This meter records the
cumulative time the engine is running.
9.4 Oil Light: Alerts the operator that there is a low oil pressure situation inside the engine.
9.5 Check Engine Light: Alerts the operator that the ECM has detected an issue with the engine
Your Bad Boy Mower Weighs:
RENEGADE SERIES: 1790 lbs.
Bypass Valve
Access
Bypass
Valve
