PAGE 26
SECTION 5: FRAME
Frame Component Maintenance
1. Torque rear wheel lugs to 65-75 ft. lbs. Re-torque
at every oil change.
2. There are two grease zerks located on each of
the two deck locating turnbuckles (4 Total).
Grease at every oil change.
3. The pump belt tensioner is located under the
engine and has a grease fitting at its pivot point.
Grease at every engine oil change.
4. The control arm blocks have grease fittings
located on each side of the steering arm bar.
Grease at every engine oil change.
5. There are 10 spherical rod ends located in the
rear suspension system that do not require
adjustment, but do require periodic cleaning and
lubrication. Bad Boy recomends using a spray
lubricant on these joints. Do this at evey oil
change and once annualy.
Grease Zerk
To Next Page
