Bad Boy RENEGADE Series User Manual

PAG
E 30
BLADE REMOVAL
To change blades, it may be easier to use a piece of
wood to keep the blade from turning so that the bolt
can be loosened. Use a 15/16" socket and impact drill,
or a wrench and an extension to gain more leverage.
Re-torque the blade bolts to 90-110 lbs.
The blade spindles contain a sealed ball earing inside
the top and bottom of the spindle. The bearings are
replaceable for a more cost-effective repair.

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
