Bad Boy RENEGADE Series User Manual

PARTS SECTION:
PAGE 39
Parts List
ITEM QTY PART NUMBER DESCRIPTION
4 4 013-0005-00
1/2" Center Lock Nut
8 6 013-0054-00 1/4-20 Cage Nut
9 6 013-2050-00 1/4-20 Hex flang lock nut
10 8 013-5019-00 10-24 Nylon Insert Locknut
11 2 013-5041-00
3/8 Nylock Nut
20 2 013-8049-00 5/16-18 Nylon Flange Nut
21 2 013-8050-00 1/2-13 Nylon Flange Nut
33 1 014-5065-00
2019 Diesel Upper Rear Cover
35 1 015-0007-00 Caterpillar Fuel Bowl Kit
37 1 015-0015-00 Auto Shut Down for Cat Diesels
39 1 015-0111-00
overflow Reservoir- 27Kaw & 28/35Hp Diesel
41 1 015-4000-00 Electric Fuel Pump
42 1 015-4010-00 ECM for 1100cc Diesel
50 2 018-0024-00 M6-1.0 X 16MM Hex Bolt
58 2 018-0067-00
1/2-13 x 3 Carriage Bolt Grade 5
63 1 018-2006-00 5/16 x 1 1/4 Hex Bolt
68
4
018-2018-00 1/2 x 3 1/2 Flange Bolt Grade 8
74 2 018-4007-00
1/4-20 x 1 GR 5 hex bolt zinc
80 2 018-5040-00 3/8" x 1 1/4" Hex Bolt
82 4 018-5200-00 10-24 X 5/8 BS Button Head Bolt
83 4 018-5250-00
3/8" x 3/4" Hex Bolt
86 1 018-5344-00 5/16" x 2 1/2" Bolt
96 6 018-8052-00 1/4" x 3/4" Hex Bolt
97 4 018-8058-00
10-24 x 1 BS C/S 18-8 SS
98 6 018-8063-00
5/16" x 3/4" Hex Bolt
106 4 019-5037-00 3/8" Lock Washer
109 2 019-6042-00 .360 ID Plastic Washer
111 2 019-8040-00
1/4" x 3/4" Carriage Bolt
112 11 019-8044-00 5/16" Flat Washer
113 6 019-8051-00 5/16" Lock Washer
118 1 021-8059-00 Heat Warning Piezo Buzzer
139 1 026-2230-00 2019 Outlaw Adjustable Foot Plate
149 6 029-4010-00 Button Bumper
Parts List
ITEM QTY PART NUMBER DESCRIPTION
153 6 030-3050-00
#10 x 1/2" Self Tapping Screw
182 14 040-6080-00 Ratchet Fastener
200 1 051-8069-00 5/16 Clear Hose x 42"
201 3 051-8075-00
5/16 Fuel Line Hose - Priced Per Foot
209 1 061-5001-98 2019 Diesel Radiator Kit
209.1 1 061-5001-00 2019 Diesel Radiator
209.2 1 014-3005-00 Electric Fan for 2019 Diesel Radiator
209.3 1 015-0104-00 radiator cap
209.4 1 026-2008-00 Screen Rentention Plate for 2019 Diesel Radiator
209.5 2 030-0090-00 1/4-20 x 3/4 Thumb Screw
209.6 1 024-0015-00
1/4 Barb to 3/16 NPT Overflow Fitting
209.7 1 015-0098-00 1/4 NPT Drain Plug
209.8 4 019-8040-00 1/4" x 3/4" Carriage Bolt
209.9 4 019-4008-00
1/4" Lock Washer
209.10 4 013-8039-00
1/4-20 Hex Nut
211 1 063-2011-00 Fuel Filter
217 1 066-8075-00 Reservoir Tank Cap-Overflow
230 1 070-5374-19 2019 Horizontal Diesel Frame
232 1 072-0001-00 3/8 Cable Clamp-Black Nylon
235
7
072-8067-00 5/8 Hose Clamp
238 1 072-8090-00
Diesel Clamp 1 3/4" Vinyl
243 1 079-3155-00 2019 Outlaw Floorboard
247 1 081-0050-00 OUTLAW2019_FLOORMAT
248 1 081-0051-00
FLOORMAT_OUTLAW_2019
249 2 084-4015-00 Rubber Trim
251 1 086-0247-19 2019 24.7 Diesel Harness
257
4
088-1999-00 2019 Outlaw Counter Weight
258 1 089-0006-00
2019 2X2 Folding ROPS
262 1 094-5088-00 Radiator Screen - Diesel
263 1 201-8025-00 2019 Diesel Radiator Mount - Front
264 1 201-8026-00 2019 Diesel Radiator Mount - Right
265 1 201-8027-00 2019 Diesel Radiator Mount - Left
FLOORBOARD, ROPS, & RADIATOR

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
