Bad Boy RENEGADE Series User Manual

Parts List
ITEM QTY PART NUMBER DESCRIPTION
20 16 013-8049-00
5/16-18 Nylon Flange Nut
24 4 013-9002-00 5/16" Flange Nut
26 1 013-9005-00 5/16-18 Nylock Jam Nut 1/2 Nut
64 4 018-2007-00
5/16" x 1" Bolt
77 1 018-4703-00
5/16" x 1 1/4" Carriage Bolt
86 2 018-5344-00 5/16" x 2 1/2" Bolt
99 3 018-8065-00 5/16" x 1" Carriage Bolt
109 4 019-6042-00 .360 ID Plastic Washer
130 2 025-0027-00 2019 Outlaw Brake Handle Spacer .625 x 1.5
137 1 026-2019-00 2019 Outlaw Seat Plate
146 1 028-0090-00
Seat Latch Rod Assembly
162 2 032-0001-00 2019 Bad Boy X Cylindrical Seat Mount
173 1 034-1025-00 Brake Spring
175 1 036-5300-00
Seat Switch Adapter
Parts List
ITEM QTY PART NUMBER DESCRIPTION
214 1 064-8054-00
2019 Short Brake Cable-Suspension Models
215 1 064-8081-00 Seat Cable
216 1 064-9002-00 2019 Long Brake Cable-Renegade, Rogue
224 1 069-0001-00 2019 Brake Handle Assembly
224.15 1 039-2136-00 2019 Brake Load Balancer - Upper Tab
224.16 1 039-2138-00 2019 Brake Load Balancer - Lower Tab
230 1 070-5374-19 2019 Horizontal Diesel Frame
231 1 071-5065-00
2019 Renegade Seat
231.1 1 071-5065-03 Backrest Cushion
231.2 1 071-5065-06 Arm Rest Kit
231.3 1 071-5065-05
Slave & Adjuster
231.4 1 071-5065-04 Seat Cushion
231.5 1 071-5065-02 Seat Belt
231.6 1 071-5065-07
Seat Switch
PARTS SECTION:
PAGE 41
SEAT & BRAKE

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
