Bad Boy RENEGADE Series User Manual

Parts List
ITEM QTY PART NUMBER DESCRIPTION
5 2 013-0021-00
Extruded Nut 3/8"-16 3/4" Hole Center With Patch
18 6 013-8043-00 5/16" Nut
19 4 013-8047-00 5/16-18 Nylock Insert Locknut
21 1 013-8050-00
1/2-13 Nylon Flange Nut
24 2 013-9002-00
5/16" Flange Nut
29 2 014-2052-00 2019 2" x .25 Rubber Grommet
34 2 014-9003-00 1 1/2 x 3 Frame Plug
60 8 018-1080-00
12-24x 1/2 HWH Bolt
63 8 018-2006-00 5/16 x 1 1/4 Hex Bolt
69 4 018-2020-18 5/16-18 BHCS, TORX DRIVE
80 1 018-5040-00
3/8" x 1 1/4" Hex Bolt
106 1 019-5037-00 3/8" Lock Washer
113 6 019-8051-00 5/16" Lock Washer
145 1 028-0051-00
2019 Steering Actuator Rod
156 1 031-0030-19
2019 R Series RH Arm Rod Assembly
156.1 1 031-0030-00 2019 Drive Arm Actuator right
156.1.1 1 031-0030-10 2019 Drive Arm Actuator right - Weldment
156.1.2 1 024-6034-00
1/4" Press in Grease Fitting
156.1.3 2 031-0032-00 2019 Drive Arm Bushing
156.2 1 031-0014-00 Drive Arm Pivot
156.3 1 013-8050-00
1/2-13 Nylon Flange Nut
156.4 2 019-8054-00 .505 Nylon Spacer
156.5 1 013-0017-00 3/8-16 Half Jam Nut
156.6 1 018-0063-00
3/8-16 x 1 Set Socket Set Screw Cup Point
156.7 1 018-0050-00
1/2-13 x 3.25 GR 5 Hex Bolt Zinc
157 1 031-0031-19 2019 R Series LH Arm Rod Assembly
157.1 1 031-0031-00 2019 Drive Arm Actuator left
157.1.1 1 031-0031-10
2019 Drive Arm Actuator left - Weldment
157.1.2 1 024-6034-00 1/4" Press in Grease Fitting
157.1.3 2 031-0032-00 2019 Drive Arm Bushing
157.2 1 031-0014-00 Drive Arm Pivot
157.3 1 013-8050-00 1/2-13 Nylon Flange Nut
157.4 2 019-8054-00 .505 Nylon Spacer
Parts List
ITEM QTY PART NUMBER DESCRIPTION
157.5 1 013-0017-00
3/8-16 Half Jam Nut
157.6 1 018-0063-00 3/8-16 x 1 Set Socket Set Screw Cup Point
157.7 1 018-0050-00 1/2-13 x 3.25 GR 5 Hex Bolt Zinc
160 1 031-9005-70
2019 Left Hand ADJ. Steering Arm Kit
160.1 1 031-9006-00
2019 Steering Arm Grip
160.2 2 031-9005-00 2019 Steering Arm Adjuster Casting
160.3 1 045-5000-00 Black Knob for Adjustable Steering Arm
160.4 1 069-4010-00
Black Steering Arm Grip
160.5 2 018-2020-18 5/16-18 BHCS, TORX DRIVE
160.6 1 018-5043-00 3/8" x 1 1/4" Carriage Bolt
160.7 2 013-8047-00
5/16-18 Nylock Insert Locknut
161 1 031-9055-70 2019 Right Hand ADJ. Steering Arm Kit
161.1 1 031-9006-00 2019 Steering Arm Grip
161.2 2 031-9005-00
2019 Steering Arm Adjuster Casting
161.3 1 045-5000-00
Black Knob for Adjustable Steering Arm
161.4 1 069-4010-00 Black Steering Arm Grip
161.5 2 018-2020-18 5/16-18 BHCS, TORX DRIVE
161.6 1 018-5043-00
3/8" x 1 1/4" Carriage Bolt
161.7 2 013-8047-00 5/16-18 Nylock Insert Locknut
163 2 032-0002-00 Snap-In Bushing-2019
174 2 035-0005-00
2019 Outlaw Gen2 Horizontal Push Rod Assembly
174.1 2 035-0005-01 2019 Outlaw Gen2 Horizontal Push Rod
174.2 2 035-0006-00 2019 Outlaw Gen2 Horizontal Push Rod Adjuster
174.3 2 013-6051-00
3/8" Fine Threaded Jam Nut
174.4 2 048-3003-00
Spherical Rod End - Outlaw
174.5 2 048-3002-00 Spherical Rod End - Outlaw
174.6 2 013-6050-00 5/16" LH Fine Threaded Jam Nut
174.7 2 013-6049-00
5/16" RH Fine Threaded Jam Nut
180 2 039-2160-00 2019 Arm Switch Bracket
204 2 057-5800-00 Speed Limiting Knob 3/8-16X 3"
230 1 070-5374-19 2019 Horizontal Diesel Frame
241 2 077-8073-00 Safety Switch
254 2 087-0002-00 2019 SROID Damper With Spherical Rod Ends
PARTS SECTION:
PAGE 43
CONTROL ARMS

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
