Page #45 background image
PARTS SECTION:
PAGE 45
Parts List
ITEM QTY PART NUMBER DESCRIPTION
6 2 013-0022-00
3/4"-16 Fine Full Nut
7 2 013-0023-00 3/4" Course Thread Nylon Lock Nut
14 8 013-5300-00 1/2" Flange Nut
15 2 013-6014-00
3/8" Hex Nut
17 8 013-7021-00
5/8 Std NC Nylock Nut
20 2 013-8049-00 5/16-18 Nylon Flange Nut
43 1 015-4600-00 18ci Parker Wheel Motor-Right
44 1 015-4601-00
18ci Parker Wheel Motor - Left
48 4 018-0015-00 1/2" x 3" Hex Bolt
55
2 018-0045-00 3/4 x 2 1/2 Course Thread Bolt
56 4 018-0049-00
AS 2465 - 5/8 x 2 3/4 UNC
64 2 018-2007-00 5/16" x 1" Bolt
70 8 018-2030-00 1/2" x 1" Hex Bolt
80 2 018-5040-00
3/8" x 1 1/4" Hex Bolt
89 4 018-6036-00
1/2" x 2 3/4" Hex Bolt
91 4 018-6059-00 5/8" x 2 1/2" Grade 5 Hex Bolt (Coarse)
93 10 018-7033-00 1/2-20 x 1-1/2 Lug Bolts Zinc
102 4 019-0009-00
5/8" Flat Washer SAE Spec Grade 8
104 12 019-5007-00 1/2" Lock Washer
107 8 019-5702-00 1/2" Washer (Grade 8)
117 2 020-7022-00
1/8x2-1/4 cotter pin Zinc
120 2 022-4090-00 2019 Assy-26x12-12 Reaper Turf 2019-10.5" Rim
Parts List
ITEM QTY PART NUMBER DESCRIPTION
120.1 2 022-4086-00 2019 10.5" Wheel
120.2 2 022-4085-00 2019 26x12-12 Reaper Turf Tire
124 4 024-2065-00 2019 Rouge/Renegade Wheel Motor 90* Fitting #6801-10L
135 4 025-7020-00
5/8" x 1/" Collar W/One Set Screw
167 2 032-7000-00 2019 Bad Boy Max Iso-Band
168 4 032-8999-00 Vibration Mount-Blue Dot
179 2 039-2145-00 2019 Suspension Gusset Outlaw
185 2 042-7041-00
Woodruff Key
189 4 048-0001-98 2019 Suspension Radius Rod Assembly
189.1 4 048-0001-00 2019 Suspension Link Body
189.2 4 048-6062-00
2019 RH 5/8" Heim
189.3 4 048-6063-00 2019 LH 5/8" Heim
189.4 4 013-0019-00 Nut, 5/8-18 RH
189.5 4 013-0020-00
Nut, 5/8-18 LH
190 2 048-7001-00
3/4-16 RH Male Rod End
226 1 070-0001-00 2019 Left Trailing Arm
227 1 070-0002-00 2019 Right Trailing Arm
230 1 070-5374-19 2019 Horizontal Diesel Frame
259 2 092-5201-00 Brake Disk
260 1 092-7000-00 XP/AOS Right Brake Caliper
261 1 092-7001-00
XP/AOS Left Brake Caliper
REAR SWING ARMS
