Bad Boy RENEGADE Series User Manual

PARTS SECTION:
PAGE 47
Parts List
ITEM QTY PART NUMBER DESCRIPTION
1 4 072-2003-00
1 1/8" Hose Clamp
2 2 072-2002-00 2-1/2" Hose Clamp
8 6 013-0054-00 1/4-20 Cage Nut
12 1 013-5201-00
3/8" Flange Nut
13 13 013-5202-00
3/8" Nylock Flange Nut
15 4 013-6014-00 3/8" Hex Nut
18 2 013-8043-00 5/16" Nut
20 10 013-8049-00
5/16-18 Nylon Flange Nut
21 4 013-8050-00 1/2-13 Nylon Flange Nut
24 3 013-9002-00 5/16" Flange Nut
27 2 014-1053-00 2019 Plastic Mesh Hose Loom
30 1 014-5060-00 2019 Horizontal Pump Cover - Right
31 1 014-5061-00 2019 Horizontal Pump Cover - Left
36 1 015-0010-50
Diesel Muffler Gasket
38 1 015-0096-00 24.7 hp Perkins Engine
38.5 1 015-0096-08 Starter
38.16 1 015-0096-09
Altenator
38.17 1 041-0010-00 Diesel Engine Belt
38.23 1 015-0096-06 Oil Pressure Sensor
38.24 1 015-0096-07 Coolant Temperature Sensor
38.26 1 015-0096-05
Fuel Shutdown Solenoid
38.27 1 015-0096-04 Barometric Pressure Sensor Bracket
38.28 1 015-0096-03 Barometric Pressure Sensor
38.29 1 013-4000-00
Pressure Sensor Nut for 1100cc Diesel
38.30 1 015-0096-01
Crank Sensor w/ nut
38.31 1 015-0096-02 Crank Sensor Bracket
38.32.1 1 015-0070-00 1100cc Diesel Thermostat
38.32.2 1 015-0071-00 1100cc Diesel Thermostat Gasket
40 1 015-1019-00 2019 Renegade 1100cc Diesel Muffler
45 1 017-3001-00
2019 Diesel Stub Shaft Double V
47 1 018-0007-00 7/16"-20 x 3" Hex Bolt Gr. 8
48 4 018-0015-00 1/2" x 3" Hex Bolt
49 6 018-0016-00
5/16-18 x 1 Button Head Torx
50 2 018-0024-00 M6-1.0 X 16MM Hex Bolt
61 2 018-2000-00 M6x1.0x 20mm 8.8 Hex Bolt
62
4
018-2001-00 M8 x 1.25 x 25mm Hex Head Bolt
63 8 018-2006-00
5/16 x 1 1/4 Hex Bolt
64 2 018-2007-00 5/16" x 1" Bolt
78 4 018-4706-00 3/8 x 1 1/2 Carriage Bolt
80 2 018-5040-00
3/8" x 1 1/4" Hex Bolt
84 2 018-5320-00 M8 x 1.25 x 30mm Hex Head Bolt
85 1 018-5321-00 M8x1.20x20MM Hex head bolt
87 6 018-6014-00
Hexagon Socket Button Head Cap Screw
88 8 018-6022-00 12mm Bolt- Diesel
90 10 018-6049-00 3/8" x 1" Hex Bolt
94 1 018-7060-00 3/8-16 x 5 1/2 Hex Bolt
99 2 018-8065-00
5/16" x 1" Carriage Bolt
100 3 018-8066-00 5/16" x 7/8" Carriage Bolt
103
4
019-4008-00 1/4" Lock Washer
Parts List
ITEM QTY PART NUMBER DESCRIPTION
104 8 019-5007-00
1/2" Lock Washer
105 8 019-5029-00 3/8" Flat Washer
106 4 019-5037-00 3/8" Lock Washer
110 2 019-7040-00
1/4" Flat Washer
112 5 019-8044-00
5/16" Flat Washer
113
7
019-8051-00 5/16" Lock Washer
114 1 019-8053-00 7/16" Lock Washer
116 1 020-2000-00
3/32 X 1/2 Cotter-pin
122 1 024-0070-00 8mm x 1/8 mpt Adaptor
123 4 024-2052-00 2019 Outlaw 90 Degree Pump Fitting #6801-10-08
125 2 024-5002-00
90 Degree Fitting, 1/2 x 3/4, 4601-8-8
126 2 024-5206-00 90 Degree Fitting, 3/8 s 9/16
132 2 025-2001-00 ACS Spacer 3/4x3/8x1/4
140 1 026-8040-00 2019 Diesel Pump Plate - Weldment
152 2 030-0075-00
5/16-24 X 3/8 Set Screw
164 4 032-4050-00 Rubber Compression Mount
165
4
032-4051-00 Snubbing Washer
170 2 033-1875-00 2019 Renegade Horizontal Pump Idler Pulley
171 2 033-5011-00 5" Pump Pulley
176 1 039-1010-00 Diesel Throttle Bracket 4 Tier
177 1 039-1015-00
Diesel Radiator Hose Clamp Bracket
178 1 039-1025-00 2019 Diesel Muffler Bracket
181 2 039-5900-00 Horizontal Tensioner
183 2 041-8000-00 2019 Renegade Pump Belt
184 2 042-5012-00 5mm x 1.25" Key
186 1 044-2006-00 1/4-5/8 Clevis Pin
191 1 050-3001-00 2019 Rogue/Renegade Left Pump 16cc
191.2 1 015-9999-00 Hydraulic Fan
191.3 1 014-5600-00 Fan Guard 6" Fits wheel Motor Pumps
192 1 050-3003-00 2019 Outlaw Renegade Right Pump 16cc
192.2 1 015-9999-00 Hydraulic Fan
192.3 1 014-5600-00 Fan Guard 6" Fits wheel Motor Pumps
193 1 051-3003-00 2019 Diesel Radiator Hose Upper
194 1 051-3004-00 2019 Diesel Air intake Hose
195 1 051-3005-00 2019 Diesel Radiator Hose Lower
196 4 051-6007-00 2019 Renegade Hydro Hose
202 1 051-8076-00 3/8 hose 4" long
205 2 057-5915-00
Pump Plate Clip Nut Holder
206 1 057-5919-00 2019 Outlaw Renegade Clutch Bracket
210 1 063-2010-00 CAT Oil Filter
228 1 070-2000-00
Clutch Pigtail
229 1 070-5040-00 Clutch for Diesel/Vanguard
233 1 072-5000-00 Diesel Hydraulic Hose Clamp
238 1 072-8090-00
Diesel Clamp 1 3/4" Vinyl
250 1 086-0003-00
Red Battery Cable Alternator to Starter Cable
252 1 086-7003-00 Coolant Temperature Sender
253 1 086-7004-00 Oil Pressure Guage with Sender
256 1 088-1010-50
Enginaire Canister VLR-Complet
266 2 201-8030-00 2019 Diesel Motor Mount - Weldment
ENGINE BAY

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
