Bad Boy RENEGADE Series User Manual

PARTS SECTION:
PAGE 49
079-3480-19
ITEM
QTY
PART NUMBER
DESCRIPTION
246 1 079-3480-19 Renegade Control Panel Assembly
246.1 1 079-3480-00 2019 Diesel Control Panel
246.2 1 077-8076-00
Ignition Switch
246.3 1 077-2076-00
USB Port
246.4 1 056-8058-00 PTO Switch
246.5 1 055-2013-00 Throttle Knob
246.6 1 055-2012-00 Universal Throttle
246.7 2 018-5200-00 10-24 X 5/8 BS Button Head Bolt
246.8 2 018-1040-00
Light Plug
246.9 2 013-5019-00 10-24 Nylon Insert Locknut
246.10 2 089-1000-00 Oil Light
246.11 1 086-7000-00 2" Oil Pressure Gauge
246.12 1 086-7001-00
2" Water Temperature Gauge
246.13 1 014-6000-00
Start Switch Boot - Diesel
246.14 1 077-6000_00 Momentary Start Switch
246.15 1 083-4013-00 Hour Meter
088-1010-50
ITEM QTY PART NUMBER DESCRIPTION
256 1 088-1010-50
Enginaire Canister VLR-Complet
256.1 1 088-1018-00 Canister for All Diesel Models
256.2 1 088-1017-00 Enginaire Air canister cap
256.3 1 063-2050-00
Diesel Air Filter- Outer
256.4 1 063-2060-00 Diesel Air Filter- Inner
256.5 1 088-1020-00 Debris Plug-Enginaire Filter
256.6 1 088-1019-00
Mounting Bracket For Diesel Air Filter
Fuel Line
ITEM QTY PART NUMBER DESCRIPTION
201 3 051-8075-00
5/16 Fuel Line Hose - Priced Per Foot
234 3 072-8050-00 5/16 Hose Clamp
235 3 072-8067-00 5/8 Hose Clamp
240 1 073-8070-00
5/16 x 5/16 x 1/4 Fuel Line T
031-0031-00
ITEM QTY PART NUMBER DESCRIPTION
157.1 1 031-0031-00 2019 Drive Arm Actuator left
157.1.1 1 031-0031-10
2019 Drive Arm Actuator left - Weldment
157.1.2 1 024-6034-00 1/4" Press in Grease Fitting
157.1.3 2 031-0032-00 2019 Drive Arm Bushing
Fuel Return Line
ITEM QTY PART NUMBER DESCRIPTION
198 2 051-8067-00 1/4 Fuel Line Hose - Priced Per Foot
199 1 051-8068-00
3/16 Fuel Line x 36"
236 4 072-8069-00 1/4 Fuel Hose Clamp
237 2 072-8070-00 3/16 Vinyl Clamp
239 1 073-2000-00
Brass fuel line T
Hydro Tanks
ITEM QTY PART NUMBER DESCRIPTION
219 1 067-8053-18 LH Rogue Hydro Tank Assy
219.1 1 067-8053-00 2019 Left Outlaw Gen2 Hydro Tank Suspension Only
219.2 1 063-8014-00 Hydraulic Filter
219.3 1 066-8050-00
Hydraulic Tank Cap W/Dipstick
219.4 2 072-8066-00
1/2 Hose Clamp
219.5 1 051-8064-21 1/2 Clear Braded Hose Priced/Foot
220 1 067-8054-18
RH Rogue Hydro Tank Assy
220.1 1 067-8054-00
2019 Right Outlaw Gen2 Hydro Tank Suspension Only
220.2 1 063-8014-00 Hydraulic Filter
220.3 1 066-8050-00 Hydraulic Tank Cap W/Dipstick
220.4 2 072-8066-00
1/2 Hose Clamp
220.5 1 051-8064-21 1/2 Clear Braded Hose Priced/Foot
031-0030-00
ITEM
QTY
PART NUMBER
DESCRIPTION
156.1 1 031-0030-00 2019 Drive Arm Actuator right
156.1.1 1 031-0030-10 2019 Drive Arm Actuator right - Weldment
156.1.2 1 024-6034-00 1/4" Press in Grease Fitting
156.1.3 2 031-0032-00 2019 Drive Arm Bushing
SUBS

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
