Bailey Caravan - OMNIVENT ROOFLIGHT MOUNTED EXTRACTION FAN (Pageant & Senator Only); Use Ventilator (Only for OMNIVENT 12 V)

4-43
Caravan Equipment
4
4.16 OMNIVENT ROOFLIGHT MOUNTED EXTRACTION FAN
(Pageant & Senator only)
4.16.1 Use Ventilator (only for OMNIVENT 12V)
The ventilator is started by the switch marked < o > (extraction or intake)
The airflow is adjusted by the black switch:
position 1 = 7m
3
/min. (245 cft/min.) (10W - 0.8 A)
position 2 = 12m
3
/min. (420 cft/min.) (25W - 2.2 A)
position 3 = 20m
3
/min. (700 cft/min.) (60W - 5 A)
▲ Allow motor to stop completely before reversing the fan direction as this may overload the
12V supply.
▲ Do not start the fan at its highest speed setting (position 3). This may result in a blown fuse
due to the high ‘start up’ current.
