4-50
4
Caravan Equipment
▲ In order to operate the Al-Ko braking system correctly adequate traction of caravan wheels
is required when reversing. Therefore surface conditions that would result in a lack of
traction should be avoided. Example: Peas, shingle/loose gravel.
▲ Care should be taken when traversing ramps or other obstacles in order to prevent damage
to the caravan under gear. When approaching such obstacles reduce towing speed
appropriately.
4.17.24 Chassis Lubrication Points
1. Grease the drawbar in the area of the bellows.
2. Grease the bearing bush through the grease
nipples on the housing and the cartridge.
3. Grease the pivot bolt of the overrun lever and
handbrake levers through the grease nipple.
4. Grease the joint of the brade rod and fitting.
5. Oil the joints of the spring cylinder in the
handbrake lever.
Lubricant type: Multi-purpose grease to DIN
51825 KTA 3K4.
4.18 REMI CARE DOOR FLYSCREEN (Pageant)
Operating Instructions
4.18.1 To close REMIcare
Pull handle/crossbar across door aperture until hook engages on closing profile.
4.18.2 To open REMIcare
a) From inside.
To release hook, pull handle/crossbar slightly toward you then, still holding the handle/crossbar, allow
the tension to pull the flyscreen back into the cassette.
b) From outside.
To release hook, push handle/crossbar away from you then, still holding the handle/crossbar, allow the
tension to pull the fly creen back in o the cassette.
▲ To avoid damage to the tension mechanism DO NOT allow the flyscreen to “whiplash”
back into the cassette.
4.18.3 Cleaning
Use a damp cloth, and if necessary, a normal household cleaner without abrasives or solvents.
▲ Do not tow with flyscreen closed. Do not leave flyscreen closed for long periods (more
than 3 weeks).
