Baja Shifter 90 Model SF90 (double-seat): Owner’s Manual Version:1.0 April 2005
43
D. Carburetor Adjustment
Never make unnecessary adjustments. The manufacturer recommended settings are correct for most
applications. It's not necessary to disassemble the screw unless the carburetor needs to be replaced. Prepare a
50r/w tachometer before the adjustment.
1) Warm up the engine for about 5~10 minutes;
2) Tighten the airscrew gently and back out 2-3/8 turns
anticlockwise;
3) Connect the tachometer, and adjust the throttle to limit
the idle speed (the standard value is 1500 RPM);
4) Slowly turn the airscrew anticlockwise; observe the RPM
of the engine, and stop the adjusting as the RPM reaches
the top speed;
5) Adjust the screw, and adjust the idle speed to an ideal value;
6) Repeat the steps d and e until the rotate speed of the engine
becomes stable.
Carburetor Idle Speed Adjust Screw
