M. Brake Cable Adjustment
1) If the brake cable is too loose, adjust the adjust nut of
the brake cable clockwise;
If the brake cable is too tight, adjust the adjust nut of the
brake cable counterclockwise;
If the adjustment doesn’t work, go on with the next step;
2) Loosen the nut M6 at the adjust bolt of the brake caliper;
If the brake cable is too loose, adjust the adjust bolt
clockwise;
If the brake cable is too tight, adjust the adjust bolt
counterclockwise;
Fasten the nut M6.
Adjust Nut
Adjust Bolt Nut M6
