Baja Shifter 90 Model SF90 (double-seat): Owner’s Manual Version:1.0 April 2005
59
L. Chain Adjustment
1) Loosen the 4 bolts M8*16 on the rear wheel axle holder,
and lift up the engine support so as to raise the rear wheel
above the ground;
2) If the chain is too loose, adjust the left and right rear
wheel bearing holders counterclockwise at the same
time;
If the chain is too tight, adjust the left and right rear
wheel bearing holders clockwise at the same
time;
3) Fasten the 4 bolts M8*16 on the rear wheel axle holder.
Bearing Holder
Bolt M8*16
Rear Wheel Axle Holder
