Steering cum Ignition Lock
To Lock the Steering : To lock the steering,
turn the handle bar to the left or right. Push
the key inside & turn toward LOCK position.
Match the lock position & turn key to LOCK
position. Lock the steering & remove the key.
To Unlock the Steering : To unlock steering,
insert the key in steering cum ignition lock &
turn it clockwise to OFF or ON position.
Key : A common key is used for Steering
cum Ignition lock, Fuel tank cap & Side cover
RH lock
Steering cum Ignition Lock :
It has three positions.
LOCK: Steering locked. Ignition OFF.
OFF: Steering unlock. Ignition OFF.
ON: Steering unlock. Ignition ON.
5
