• The heating coil in the hose is
damaged and the hose may
need to be replaced.
• How to replace heated hose:
Disconnect the machine from
electrical supply; release the
spray gun (1) from the hose by
removing retaining clamp (2).
Unscrew the feed socket (3).
Remove the two plug
connections (4) from the gun
hose. Remove the gun hose by
removing the retaining clamp
(5). Fit the new gun hose in
reverse order to the foregoing.
