TP800 Panel Configuration
Button Layout Table
Feature
#
Setup 1 Setup 2 Setup 3 Setup 4 Setup 5 Setup 6
A1
N/A N/A N/A N/A N/A N/A
A2
Jets 1 Jets 1 Jets 1 Jets 1 Jets 1 Jets 1
A3
Jets 2 Jets 2 Blower Blower Light 1 Light 1
A4
Light 1 Light 1 Light 1 Light 1 Invert Invert
A5
Invert Invert Invert Invert (Circ Icon) Undefined
A6
(Circ Icon) Undefined (Circ Icon) Undefined Undefined Undefined
A7
Undefined Undefined Undefined Undefined Undefined Undefined
A8
Undefined Undefined Undefined Undefined Undefined Undefined
A9
Undefined Undefined Undefined Undefined Undefined Undefined
A10
Undefined Undefined Undefined Undefined Undefined Undefined
A11
N/A N/A N/A N/A N/A N/A
A12
N/A N/A N/A N/A N/A N/A
A13
Undefined Undefined Undefined Undefined Undefined Undefined
A14
Undefined Undefined Undefined Undefined Undefined Undefined
A15
Undefined Undefined Undefined Undefined Undefined Undefined
A16
Undefined Undefined Undefined Undefined Undefined Undefined
B1
Jets 1 Jets 1 Jets 1 Jets 1 Jets 1 Jets 1
B2
Jets 2 Jets 2 Blower Blower Undefined Undefined
B3
Undefined Undefined Undefined Undefined Undefined Undefined
B4
Light 1 Light 1 Light 1 Light 1 Light 1 Light 1
TP800 is not supported in Setup 7.
