Template 56377 10-05-12
15
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2,
Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. © Copyright 2009 Balboa Water Group.
59293-01_59294-01_59295-01_B 05-10-21
Replacement Parts
PCBA:
Main PCBA: 59499
Expander PCBA (user-installed): 59232 (X-P) for Pump2; 59231 (X-B) for Blower
HEATER(s):
Heater: 58421 5.5kW 800Inc -- for integral heater only
58426 4.0kW 800Inc -- for integral heater only
Temp Sensor Kit: 30344KIT 12-inch sensor -- for integral heater only
30382KIT 24-inch sensor -- for integral heater only
FUSES:
Part Number Amperage* Location
30136 30A F6
26983 1A F4, F5 on main board
24514 0.1A F3 when using 240V heater
26982 0.16A F3 when using 120V heater
30122 10A F5 on X-B expander when using Blower in Setup 3 or 4
* The amperages shown above are only intended for identifying fuses on our boards.
They are not complete descriptions of those fuses. Please use the part numbers at
the left to order fuses directly from Balboa.
