b、INSTALLATION ENVIRONMENT LAYOUT REQUIREMENTS
1. Machine room should be close to the load centre, so as to shorten the length of pipe, reduce
the pressure loss & power consumption, and guarantee the air supply pressure.
2. Consider the rationality of the power supply, water supply when planning the room
position.
3. There should be enough lands for expanding around the room in order to adapt to the
needs of the development.
4. Air compressor directly sucks air. In order to lower the possibility of the machine’s
wearing, corrosion and explosion, there must be a certain distance between the air
compressor room and the place which sends out explosive, corrosive, poisonous gas, dust and
other harmful substances. What’s more, the room should be located in the place of the
minimum frequency wind to make sure it is affected the least by harmful substances. The
distance between compressor and harmful substance emission source is suggested. Please see
the table2-1 below.
Distance between compressor and harmful substance emission source
the name of harmful substance
emission source
the relation with the
wind orientation
level distance(m)
the place which will send out
flammable gas(acetylene, gas)
any wind orientation
≥20
the chimney and discharge pipe
which send out dust
The underside of local
minimum frequency wind
≥50
the place which sends out dust
unfavorable wind
favorable wind
≥50
≥20
