FIGURE 4 – MECHANICAL SPECIFICATIONS (INCHES/MM)
Side View is shown dimensioned
with the cover installed.
Recommended tightening torque for the
two (2) front cover screws are, 5 inch lbs (6 kg-cm).
Back View is shown dimensioned
without the cover installed.
"Knockouts" for Standard
3
4
inch Fittings.
109
4.30
126
4.95
7.6
0.30
5.08
0.2
0.39
9.91
4X Ø
4X Ø
27.9
1.10
5.10
130
7.00
178
9.0
0.35
3.20
81.3
Feed-Through Bushing
1.75
44.5
0.95
130
5.10
24.1
59.7
2.35
1.45
36.8
25.4
1.00
4.15
105
0.95
24.1
1.10
27.9
Note: All Dimensions are measured in "Inches & mm".
