TABLE 1 - STANDARD FEATURES
Feature Description
Simple to Operate
Does not require programming. Uses
trimpots and jumpers which are factory set
for most applications.
Dual AC Line Voltage (115 or 208/230 Volt AC
Operation)
Controls 208 – 230 Volt AC, 50 & 60 Hz,
3-phase motors from 115 or 208/230 Volt
AC line. (Jumper J1 must be installed for
115 Volt AC line operation.)
Motor Horsepower Selection Jumper
Allows the drive to be used on a wide
range of motor horsepower (1/8, 1/4, 1/2,
3/4, 1 HP) without recalibration or
programming.
Diagnostic LED’s
PC board mounted LEDs for Power on
(ON), Drive Status (ST), and Overload
(OL).
Run/Fault Relay Output Contacts
Can be used to turn on and off equipment
or to signal a warning if the drive is put
into a Stop Mode or a fault has occurred.
Barrier Terminal Blocks
Facilitate wiring of AC line, motor, ground
(earth) and Run/Fault Relay Output
Contacts.
On/Off AC Line Switch
Panel mounted. Used to turn on or off
power to the drive.
Pilot Light
Panel mounted. Indicates that power is
applied to the drive and the On/Off AC
Line Switch is set to the “ON” position.
Main Speed Potentiometer
Panel mounted. Provides adjustment of
motor speed.
Jumper Selections of Drive Output Frequency
Increases the motors speed up to two
times the rated RPM.
TABLE 2 - PERFORMANCE FEATURES
Feature Description
Power Start™
Provides more than 200% starting torque
which ensures startup of high frictional
loads.
Flux Vector Compensation with Static Auto-Tune
and Boost
Provides excellent load regulation over a
wide speed range.
Speed Range 60:1
