4 Take out the 4 screws of the grille and remove the grille.
grille and remove the grille.
）
Screws
4
1
3 and evaporator ASS Y
Take out the room temperature sens or and coil sensor on the evapa rator
．
）
）
） '
.
Remove the electri cal control box
1 Take out the screw of the electri ca l cover and remove it.
2 Remove the indoor coi l sens or from the s ens or bra ck et.
3 Ta ke out the screws of the electrical control box and disconnect all the connectors on the printed ci rcui t board ,
Screws
the electrical cover
Room temperature sensor
Display connector pl ug
then remove the electri cal box .
5. Remove the evap orator .
2) Ta ke out the 6 s crews of the evaporator supportor and remove the evaporator s upp ortor.
Screws
Screws
Coil sensor
Electrical box
Fan motor plug
Stepp er motor p l ug
Screw
