2-3. Other component specifications
2-3-1. INDUCTANCE
ELECTRIC PERFORMANCE PARAMETER
Inductance model -
Rated power source -
Loop winding rated current - Rated
current(A)
Filter winding rated current -
Loop winding rated inductance - Rated
inductance
(mH)
Filter winding rated inductance -
Ambient temperature( )℃ -
2-3-2. INDUCTANCE (1343046,A)
ELECTRIC PERFORMANCE PARAMETER
Inductance model R1250HSB
Rated power source 220V 50Hz
Rated current(A) 12
Rated inductance(mH) 5
Ambient temperature( )℃
-20℃～
+70 .℃
2-3-3. FILTER
ELECTRIC PERFORMANCE PARAMETER
Filter model RTLB-12T047-02JF
Rated current(A) 12
Rated power source 220V 50Hz
Filter frequency range 150K—30MHHz
Temperature range( )℃
-25℃～+85℃
.
2-3-4. STEPPER MOTOR
ELECTRIC PERFORMANCE PARAMETER
Stepper Motor model 24BYJ48
Voltage(DC) 12V
Number of phase 4
Drive mode 1-2phase excitation unipolar drive
Resistance per phase
200Ω
±7%
Temperature range( )℃
-10℃～
+40 .℃
