1.Remove the top panel the front panel
1)Take out the 8 screws of the top panel and remove the top panel.
8 screws Top panel
2. Remove the front panel
1)Take out the 9 screws of the top panel and remove the panel.
Front panel
9 Screws
3. Remove the side panel
1)Take out the 1 screws of the side cover and remove the cover.
1 screws side cover
BSGI 09(12)
