CON2-P37 PA17-EINT17 PA17-EINT17 SPDIF-OUT
CON2-P38 PA21-EINT21 PA21-EINT21
CON2-P39 GND
CON2-P40 PA20-EINT20 PA20-EINT20
CSICameraConnectorspecification:
TheCSICameraConnectorisa24-pinFPCconnectorwhichcanconnectexternalcameramodulewithpropersignalpin
mappings.ThepindefinitionsoftheCSIinterfaceareshownasbelow.ThisismarkedontheBananaPiboardas“CSI″.
CSIPinName DefaultFunction Function2：GPIO
CN3-P01 NC
CN3-P02 GND
CN3-P03 CSI0-SDA PE13
CN3-P04 CSI0-AVDD
CN3-P05 CSI0-SCK PE12
CN3-P06 CSI0-Reset PE14
CN3-P07 CSI0-VSYNC PE3
CN3-P08 CSI0-PWDN PE15
CN3-P09 CSI0-HSYNC PE2
CN3-P10 CSI0-DVDD
CN3-P11 CSI0-DOVDD
CN3-P12 CSI0-D7 PE11
CN3-P13 CSI0-MCLK PE1
CN3-P14 CSI0-D6 PE10
CN3-P15 GND
CN3-P16 CSI0-D5 PE9
CN3-P17 CSI0-PCLK PE0
CN3-P18 CSI0-D4 PE8
CN3-P19 CSI0-D0 PE4
CN3-P20 CSI0-D3 PE7
CN3-P21 CSI0-D1 PE5
CN3-P22 CSI0-D2 PE6
CN3-P23 GND
CN3-P24 CSI0-DOVDD
UARTspecification:
ThejumperCON3istheUARTinterface.FordevelopersofBananaPi,thisisaneasywaytogettheUARTconsoleoutput
tocheckthesystemstatusandlogmessage.
BPI-M2+Pindefine
