MODEL 200 UC REPLACEMENT PARTS
** Components vary with engine options order by physical description or machine S/N.
*-* Contact your nearest dealer or Bandit Industries for Fan Blade Assemblies.
# Part Number Description
1
See Page 75 Anvil & Hardware
2
980-0119-57
Front Chipper Bearing Cover
Mount Tab
3
980-200217 Front Chipper Bearing Cover
4
900-4903-45
Bearing Retainer Bolt -
3/4”-10NC x 2 3/4” Hex Head
900-4907-17 3/4” Lock Washer
5
980-0125-10 Bearing Retainer
6
900-4903-32
Chipper Bearing Bolt -
5/8”-11NC x 1 3/4” Hex Head
900-4906-87 5/8” Lock Washer
7
900-1900-33 Front Chipper Bearing
8
980-0119-39
Optional Front Chipper Bearing
Backer Plate
9
980-0125-34 1/16” Chipper Disc Spacer
980-0101-73 1/8” Chipper Disc Spacer
980-0101-74 3/16” Chipper Disc Spacer
980-0101-75 1/4” Chipper Disc Spacer
995-0001-04 5/16” Chipper Disc Spacer
995-0001-05 3/8” Chipper Disc Spacer
10
980-0132-76 Chipper Shaft - 18” Long
11
980-0121-65
Optional Rear Chipper Bearing
Backer Plate
12
900-1900-34 Rear Chipper Bearing
13
** Pump Mount (If Applicable)
14
900-3921-02 Chipper Bearing Grease Line
15
980-0132-87 Hood Stop
16
955-1015-32 Chipper Disc Lock Pin
17
See Page 74 Chipper Knife & Hardware
18
980-2003-36
2-Knife Chipper Disc Assembly
- 1/2” Thick Knife, 5/8” Bolt
19
980-0123-82 Chipper Disc Lock Tube
20
900-4926-78
Chipper Draw Ring Bolt -
5/8”-18NF x 5 1/4” Hex Head
21
980-0126-63 Chipper Draw Ring
22
900-4907-06
Chipper Draw Ring Nut - 5/8”-
18NF High Hex Nut
23
*-* Fan Blade Assembly
# Part Number Description
24
980-100006 Chipper Hood - Hinged Half
25
900-4902-20 Padlock for Hood Pin
900-4917-21 Key for Padlock
26
909-1000-01
Engine Disable Plug Kit (Includes
Plug, Wiring, & Mounts)
900-2904-13 6-Prong Female Plug Only
980-100083
6-Prong Male Plug with Wire
Loop & Crimp Sleeves
27
980-0123-29 Hood Pin with Attaching Chain
28
980-1002-09 Spring Lock for Hood Pin
900-7900-93 Black Vinyl Cap
29
980-300349 Hood Flange
30
980-3013-58 Bottom Swivel Ring
31
900-4908-27 Discharge Spring Lock
900-7900-96 Rubber Cap
32
980-100007
Chipper Hood - Stationary Half
(Manual Discharge)
980-1004-49
Chipper Hood - Stationary Half
(Hand Crank Swivel Discharge)
33
** Chipper Belts
34
** Chipper Sheave
35
** Chipper Bushing
36
** Hydraulic Pump Belts (If Applicable)
37
** Engine Sheave Bushing
38
** Engine Sheave
39
905-3005-33
Adjustable Beltshield Cover - 6”
Diameter
905-3005-35
Adjustable Beltshield Cover - 5
1/4” Diameter
905-3005-37
Adjustable Beltshield Cover - 7
5/8” Diameter
980-300295
Adjustable Beltshield Cover -
Twin Disc Clutch SP211
980-300240
Adjustable Beltshield Cover -
Twin Disc Clutch SP111
980-300413
Adjustable Beltshield Cover -
Auto Clutch
40
980-2004-59 Beltshield Assembly
CHIPPER ASSEMBLY
